Template Tags Reference

End User , Established , P5 , Box Doc Gen
Note: Box Doc Gen template tags currently support English only. Test your templates to verify they meet your language requirements before production use.

Template tags let you create document templates that automatically fill in with data. When you generate a document, Box Doc Gen finds the tags in your template, matches them to fields in your JSON input, and replaces each tag with the corresponding value.

Use template tags to dynamically generate:

  1. Text
  2. Images
  3. Tables
  4. Lists
  5. Conditions
  6. Calculations
  7. Box Sign template tags

1. Text tags

A text tag is any data field of type, string, number, or date. In the example below, you can turn id, date, customerId, customerName, currency, amount into text tags.

{
  "invoice":{
    "id": "Inv1203",
    "date": "13-03-2023",
    "customerId": "90158",
    "customerName": "Acme Inc",
    "currency": "$",
    "amount": 5060.50
  }
}

In the output document generated, all the template tags will be replaced with the input data.

Note: Box Doc Gen tags do not support spaces or hyphens between key words in the tag. For example, {{first name}} or {{first-name}} are not supported.
Document template Output document

Invoice

Invoice id: {{invoice.id}}

Invoice date: {{invoice.date}}


Customer details:
Customer id: {{invoice.customerId}}
Customer name: {{invoice.customerName}}


Amount Payable:

{{invoice.currency}}{{invoice.amount}}

Invoice

Invoice id: Inv1203

Invoice date: 13-03-2023


Customer details:
Customer id: 90158
Customer name: Acme Inc


Amount Payable:

$5060.50



Optional tags

Input format Input data Output data
{{invoice.customerName}} - {{invoice.customerName}}
{{invoice.customerName :: optional}} -



Default values

Input format Input data Output data
{{invoice.customerName}} - {{invoice.customerName}}
{{invoice.customerName :: default(“Box Inc”)}} - Box Inc



Formatting text tags

Input format Input data Output data Supported
via script 		Supported
via Add-in
{{invoice.customerName :: uppercase}} Acme Inc ACME INC Yes No
{{invoice.customerName :: lowercase}} Acme Inc acme inc Yes No
{{invoice.date :: format(
“dd-mm-yyyy”) }} 		13-03-2023 13-03-2023 Yes No
{{invoice.date :: format(“mm-dd-yyyy”) }} 13-03-2023 03-13-2023 Yes No
{{invoice.date :: format(“dd-mmm-yy”) }} 13-03-2023 13-Mar-22 Yes No
{{invoice.id :: format(“xxx-xxxx”) }} Inv1203 Inv-1203 Yes No
{{invoice.amount :: format(“EU-Number”) }} 300000 300.000 Yes No
{{invoice.amount :: format(“US-Number”) }} 300000 300,000 Yes No



Rich text

Box Doc Gen allows you to generate documents with rich text. If the input JSON data contains HTML tags such as bold, italic, underline, line breaks, paragraphs, anchors, or images, Doc Gen automatically interprets them as rich text and applies the relevant formatting.

HTML Tags JSON data Output
Bold { "company": "<b>Acme Inc.</b> A fictional company that features prominently in the Road Runner show as a running gag. Phone:<b> 999-999-9999</b>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Italic { "company": "<i>Acme Inc.</i> A fictional company that features prominently in the Road Runner show as a running gag. Phone:<i> 999-999-9999</i>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Underline { "company": "<u>Acme Inc.</u> A fictional company that features prominently in the Road Runner show as a running gag. Phone:<u> 999-999-9999</u>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Bold, Italic and Underline { "company": "<b><i><u>Acme Inc.</u></i></b>A fictional company that features prominently in the Road Runner show as a running gag. Phone:<b><i><u> 999-999-9999</u></i></b>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Strong { "company": "<strong>Acme Inc.</strong> A fictional company that features prominently in the Road Runner show as a running gag. Phone:<strong> 999-999-9999</strong>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Span { "company": "<span>Acme Inc.</span> A fictional company that features prominently in the Road Runner show as a running gag. Phone:<span> 999-999-9999</span>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Emphasized { "company": "<em>Acme Inc.</em> A fictional company that features prominently in the Road Runner show as a running gag. Phone:<em> 999-999-9999</em>" } Acme Inc. A fictional company that features prominently in the Road Runner show as a running gag. Phone: 999-999-9999
Line breaks { "company": "<b>Acme Inc.</b>  \n A fictional company that features prominently in the Road Runner show as a running gag. \n Phone:<b> 999-999-9999</b>" }

Acme Inc.

A fictional company that features prominently in the Road Runner show as a running gag.

Phone: 999-999-9999
Paragraphs { "company": "<b>Acme Inc.</b>  <p> A fictional company that features prominently in the Road Runner show as a running gag. </p>  <p> Phone:<b> 999-999-9999</b>"</p> }

Acme Inc.

A fictional company that features prominently in the Road Runner show as a running gag.

Phone: 999-999-9999
Ordered list <ol><li>Blue</li><li>Green</li><li>Red</li></ol>
  1. Blue
  2. Green
  3. Red
Unordered list <ul><li>Blue</li><li>Green</li><li>Red</li></ul>
  • Blue
  • Green
  • Red



2. Image tags

An image tag can be used to dynamically add and render images. Box Doc Gen supports images in base64 format.

To add image tags to your Box Doc Gen template:

  1. Insert a placeholder image, position it, and resize it to your needs
  2. Add a $image-path variable to the image under Alt text. Under the image path, refer to the variable in the JSON data that holds your image in base64.
    For the sample JSON code below, we refer to contract.logo to have the base64:
{
"image-path": "contract.logo”,
"alt-text": "Alt text"
}

During the document generation process, Box Doc Gen replaces the placeholder image with the base64 value associated with the key identified.

{
  "contract":{
    "customerId": "1203",
    "date": "18-08-2023",
    "country": "UK",
    "customerName": "Example Corporation",
    "logo": "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",
    "customerAddress":{
      "street": "Example street",
      "city": "Example city",
      "zip": "EX-456"
    }
  }
}

Document Template

Output

Box Doc Gen replaces the placeholder image with the base64 value associated with the key identified.

The output on the generated document will display as follows:

3. Table tags

An array from the input data can be used to generate and dynamically format a table.

In the following example:

  • items is an array that can be rendered as a dynamic table.
  • id, name, quantity, price, amount are the variables within the array that can be rendered as individual columns to the dynamic table.
{
  "invoice":{
    "number": "Inv1203",
    "date": "13-03-2023",
    "customerId": "90158",
    "currency": "$",
    "amount": 5060.50,
    "items": [
      {
        "id": 1,
        "name": "A4 Papers",
        "quantity": 100,
        "price": 29,
        "amount": 2900
      },
      {
        "id": 2,
        "name": "Ink  Cartridge",
        "quantity": 40,
        "price": 39,
        "amount": 1560
      },
      {
        "id": 3,
        "name": "Adhesive tape",
        "quantity": 20,
        "price": 30,
        "amount": 600.50
      }
    ]
  }
}

Document Template

The document template with inserted tags will look as follows:

Id Name Qty Price
{{tablerow item in invoice.items}}
{{item.id}} {{item.name}} {{item.quantity}} {{item.price}}
{{endtablerow}}

Output

Box Doc Gen automatically identifies the table tags added to the document template, matches them with the fields in the input JSON data, and performs a few iterations to generate a complete table for the input data.

The output table on the generated document will look as follows:

Id Name Qty Price
1 A4 Papers 100 29
2 Ink  Cartridge 40 39
3 Adhesive tape 20 30



4. List tags

An array from the input data can be used to dynamically generate an ordered or unordered list.

In the following example:

  • items is an array that can be rendered as a dynamic list.
  • id, name, quantity, price, amount are the variables within the array that can be rendered as a repetitive field in the list.
{
  "invoice":{
    "number": "Inv1203",
    "date": "13-03-2023",
    "customerId": "90158",
    "currency": "$",
    "amount": 5060.50,
    "items": [
      {
        "id": 1,
        "name": "A4 Papers",
        "quantity": 100,
        "price": 29,
        "amount": 2900
      },
      {
        "id": 2,
        "name": "Ink  cartridge",
        "quantity": 40,
        "price": 39,
        "amount": 1560
      },
      {
        "id": 3,
        "name": "Adhesive tape",
        "quantity": 20,
        "price": 30,
        "amount": 600.50
      }
    ]
  }
 }

The input data can be used to generate different types of lists:

Use case Document template Output document
Adding a bullet list

List of products:

{{ for item in invoice.items }}

  • {{item.name}}

{{ endfor }}

List of products:

  • A4 Papers
  • Ink cartridge
  • Adhesive tape
Adding a bullet list with one or more variables

List of products:

{{ for item in invoice.items }}

  • {{item.name}}, {{item.quantity}}

{{ endfor }}

List of products:

  • A4 Papers, 100
  • Ink cartridge, 40
  • Adhesive tape, 20
Adding a squared bullet list with one or more variables

List of products:

{{ for item in invoice.items }}

  • {{item.name}}, {{item.quantity}}

{{ endfor }}

List of products:

  • A4 Papers, 100
  • Ink cartridge, 40
  • Adhesive tape, 20
Adding a white bullet list with one or more variables

List of products:

{{ for item in invoice.items }}

  • {{item.name}}, {{item.quantity}}

{{ endfor }}

List of products:

  • A4 Papers, 100
  • Ink cartridge, 40
  • Adhesive tape, 20
Adding a numbered list with one or more variables

List of products:

{{ for item in invoice.items }}

  1. {{item.name}}, {{item.quantity}}

{{ endfor }}

List of products:

  1. A4 Papers, 100
  2. Ink cartridge, 40
  3. Adhesive tape, 20
Adding a roman numbered list with one or more variables

List of products:

{{ for item in invoice.items }}

  1. {{item.name}}, {{item.quantity}}

{{ endfor }}

List of products:

  1. A4 Papers, 100
  2. Ink cartridge, 40
  3. Adhesive tape, 20
Adding an alphabetical list with one or more variables

List of products:

{{ for item in invoice.items }}

  1. {{item.name}}, {{item.quantity}}

{{ endfor }}

List of products:

  1. A4 Papers, 100
  2. Ink cartridge, 40
  3. Adhesive tape, 20

Formatting lists

Box Doc Gen templates support a wide range of custom codes that you can use in the document template. Taking the following JSON input data as an example, you can introduce different separators and delimiters.

{
  "items": ["A4 Papers", "Ink  cartridge", "Adhesive tape"]
}
Type of list Document template Output document
List - with comma separator  {{ items :: delimiter(“,”)}} A4 Papers, Ink cartridge, Adhesive tape
List - with semicolon separator  {{ items :: delimiter(“;”)}} A4 Papers; Ink cartridge; and Adhesive tape
List - with customer separator {{ items :: delimiter(“~”)}} A4 Papers~ Ink cartridge~ Adhesive tape
List - with Comma and last delimiter {{ items :: delimiter(“,”) , lastdelimiter (“, and”)}} A4 Papers, Ink cartridge, and Adhesive tape
List - with semicolon and last delimiter {{ items :: delimiter(“;”) , lastdelimiter (“; and”)}} A4 Papers; Ink cartridge; and Adhesive tape
List - with custom separator and last delimiter {{ items | delimiter(“~”)}}, lastdelimiter (“~ and”)}} A4 Papers~ Ink cartridge~ and Adhesive tape



5. Conditions

You can use conditions to add input to the output document. The Box Doc Gen Template Creator add-in can help you define these conditions within the document template.

Supported conditions and operators

Tag type Conditions supported Operators supported to chain conditions
String ==(is equal to), !=(is not equal to), isPresent AND, OR
Date isPresent AND, OR
Number <, >, ==, !=, >=, <= AND, OR

The following JSON serves as input for defining conditions for the Box Doc Gen template.

{
  "invoice":{
    "number": "Inv1203",
    "date": "13-03-2023",
    "customerId": "90158",
    "currency": "$",
    "amount": 5060.50,
    "paymentMethod": "Cheque",
    "paymentTerms": "Net60",
    "deliveryDate": "23-03-2023",
    "items": [
      {
        "id": 1,
        "name": "A4 Papers",
        "quantity": 100,
        "price": 29,
        "amount": 2900
      },
      {
        "id": 2,
        "name": "Ink cartridge",
        "quantity": 40,
        "price": 39,
        "amount": 1560
      },
      {
        "id": 3,
        "name": "Adhesive tape",
        "quantity": 20,
        "price": 30,
        "amount": 600.50
      }
    ]
  }
 }
Use case Document template Output document
Introducing content based on payment method and payment terms

Payment terms:

{{ if invoice.paymentMethod == “Online Transfer” AND invoice.paymentTerms == “Net30” }}

  • The invoice must be paid within 30 calendar days of the invoice date.
  • The payment reference should contain the invoice number as reference.

{{ elseif invoice.paymentMethod == “Cheque” AND invoice.paymentTerms == “Net60” }}

  • The invoice must be paid within 60 calendar days of the invoice date.
  • The payment reference should contain the invoice number as reference.
  • CHECK MADE PAYABLE TO: Box Inc, 900 Jefferson Ave, Redwood City, CA 94063, United States.

{{else}}

  • The invoice must be paid must pay within 7 calendar days of the invoice date.

{{endif}}

Payment terms:

  • The invoice must be paid within 60 calendar days of the invoice date.
  • The payment reference should contain the invoice number as reference.
  • CHECK MADE PAYABLE TO: Box Inc, 900 Jefferson Ave, Redwood City, CA 94063, United States.
Adding processing fees based on invoice amount, and payment method

Processing fees:

{{ if invoice.amount >  1000 AND invoice.amount < 5000 AND invoice.paymentMethod == “Cheque” }}

  • There will be an additional 1% processing fee that will be added to your account.
  • The processing fee will be included to your next invoice.

{{ elseif invoice.amount > 5000 AND invoice.paymentMethod == “Cheque”}}

  • The invoice can be paid via check or online transfer without any added processing fees.

{{else}}

  • The invoice must be paid within 7 calendar days of the invoice date.

{{endif}}

Processing fees:

  • The invoice can be paid via check or online transfer without any added processing fees.
Adding delivery terms based on delivery date on invoice

Delivery terms:

{{ if invoice.deliveryDate isPresent }}

  • Your order shall be delivered on {{ invoice.deliveryDate}}.
  • Orders delivered can be returned within 10 days of delivery.

{{else}}

  • Your order shall be delivered within the next 7 days.
  • Orders delivered can be returned within 10 days from the date of delivery.

Delivery terms:

  • Your order will be delivered on 23-03-2023.
  • Orders delivered can be returned within 10 days of delivery.

Conditions with tables

Doc Gen allows you to conditionally render any content including tables, images, and so on.

{{ if invoice.customerId isPresent }}

Id Name Qty Price
{{tablerow item in invoice.items}}
{{item.id}} {{item.name}} {{item.quantity}} {{item.price}}
{{endtablerow}}

{{ endif }}

Conditions inside tables

Doc Gen allows you to conditionally render content with a column in a table.

Examples

Id Name Qty Price
{{ tablerow item in invoice.items }}
{{ item.id}} {{ item.name}} {{ item.quantity}} {{ if item.price isPresent}}{{item.price}}{{ else }}-{{ endif }}
{{ endtablerow }}



6. Calculations

Box Doc Gen templates support dynamic calculations. You can either write the computation code to the tagging language manually, or use the Box Doc Gen Template Creator add-in.
Sample code calculations include:

  • Invoice: Determining the net invoice amount from individual line items.
    Example: Sum (Individual Line item amounts in the invoice)
  • Purchase order: Capping the maximum sourcing amount.
    Example: 5% * Net Order Value
  • Sales contracts: Defining penalty on SLA breach.
    Example: 10% * Total Sales Value

Supported operations

Arithmetic operations Aggregation operations
% Percent
+ SUM
* AVERAGE
- COUNT

The following JSON serves as input for adding calculations to the document template.

{
  "invoice":{
    "number": "Inv1203",
    "invoiceDate": "13-03-2023, 12:10 PM",
    "deliveryDate": "23-03-2023",
    "customerId": "90158",
    "currency": "$",
    "taxRate": 3,
    "taxAmount": 151.8,
    "shippingCharge": 15,
    "grossAmount": 5060,
    "penaltyRate": 10,
    "billCap": 25,
    "items": [
      {
        "id": 1,
        "name": "A4 Papers",
        "quantity": 100,
        "price": 29,
        "amount": 2900
      },
      {
        "id": 2,
        "name": "Ink  cartridge",
        "quantity": 40,
        "price": 39,
        "amount": 1560
      },
      {
        "id": 3,
        "name": "Adhesive tape",
        "quantity": 20,
        "price": 30,
        "amount": 600
      }
    ]
  }
}

Examples:

Use case Document template Output document

To calculate net amount from the given Gross Amount and Tax Amount

Arithmetic calculation

 Net Amount:
{{ invoice.grossAmount + invoice.taxAmount}}

Net Amount:
5211,8

Annotation:
5060 (grossAmount) + 151.8 (taxAmount)

To calculate net amount from the given Gross Amount, Tax Rate and Shipping Charge

Arithmetic calculation

 Net Amount:
{{ invoice.grossAmount + invoice.taxAmount + invoice.shippingCharge}}

Net Amount:
5226.8

Annotation:
5060 (grossAmount) + 151.8 (taxAmount) + 15 (shippingCharge)

To calculate tax amount from the given Tax Rate and Gross Amount

Arithmetic calculation

 Tax Amount:
{{ invoice.taxRate % * invoice.grossAmount}}

Tax Amount:
151.8

Annotation:
3% (taxRate)  * 5060 (grossAmount)

To calculate gross amount from individual line item amounts

Aggregation calculation

 Gross Amount:
{{ $sum(invoice.items.amount) }}

Gross Amount:
5060

Annotation:
Sum (2900+1560+600)

To calculate number of line items

Count calculation

 Count:
{{ $count(invoice.items.amount) }} 		Count:
3
To calculate average of line items Average Amount:
{{ $average(invoice.items.amount) }} 		Average Amount:
1686.66

To calculate net amount from the given Line Item Amount, and Tax Rate

Arithmetic + Aggregation calculation

 Net Amount:
{{ $sum(invoice.items.amount) + invoice.taxRate % * $sum(invoice.items.amount)}}

Net Amount:
5211,8

Annotation:
Sum (2900+1560+600) +
3% * Sum (2900+1560+600)



7. Box Sign template tags

Box Sign template tags can be added to the Box Doc Gen template for the output document created via Box Box Doc Gen to be sent for e-signature.

The table below lists the tags available in the Box Doc Gen Template Creator add-in and the tagging script.

Field Box Sign’s template code Supported
via tagging script 		Supported
via add-in
Text field [[t|0]] Yes Yes
Date field [[d|0]] Yes Yes
Checkbox field [[c|0]] Yes Yes
Signature field [[s|0]] Yes Yes
Stamp field type [[st|0]] Yes Yes
Initials field type [[i|0]] Yes Yes
Name field type [[n|0]] Yes Yes
First name field type [[fn|0]] Yes Yes
Last name field type [[ln|0]] Yes Yes
Company field type [[co|0]] Yes Yes
Email field type [[e|0]] Yes Yes
Title field type [[ti|0]] Yes Yes
For an attachment field type [[a|0]] Yes Yes

Related articles
